21.5" LCD screen module AUO TFT Display 25Ms Response Time

Place of Origin Shenzhen
Brand Name DYMONA
Certification CE,SGS,ROHS,ISO9001
Model Number MxxxxX60-156-0601
Minimum Order Quantity 1pcs
Price Negotiable price
Packaging Details Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Supply Ability 1KK pcs

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Origin Place Shenzhen Resolution 1920(RGB)×1080, FHD
Viewing Angle 89/89/89/89 Operating Temperature -20 ~ 50 °C
Storage Temperature -20 ~ 60 °C Contrast Ratio 1000 : 1
Panel Brand AUO Response Time 25 Ms
High Light

AUO 21.5" LCD Screen Module


AUO TFT Display 25Ms Response Time


21.5" AUO TFT Display

Leave a Message
Product Description

Shenzhen 21.5" LCD TFT Display Module for B2B Market

Product Description:

The IPS TFT Display Module is a high-performance LCD display with a 5.0V voltage supply. It features a RGB Vertical Stripe pixel format and can operate in either ADS, Normally Black, or Transmissive work mode. The display has a viewing angle of 89/89/89/89 and a wide temperature range of -20°C to 60°C, making it ideal for use in a variety of different environments. This versatile TFT LCD screen module is designed to deliver bright and vivid visuals with a high level of color accuracy.



  • Product Name: TFT Display Module
  • Refresh Rate: 60Hz
  • Interface Type: LVDS 30 Pins Connector
  • Size: 21.5"
  • Brightness: 1500 Cd/m²
  • Resolution: 1920(RGB)×1080, FHD
  • Color LCD Display Module
  • LCD Display Screen
  • LCD TFT Display Module

Technical Parameters:

Parameters Details
Storage Temperature -20 ~ 60 °C
Interface Type LVDS 30 Pins Connector
Viewing Angle 89/89/89/89
Brightness 1500 Cd/m²
Work Mode ADS, Normally Black, Transmissive
Pixel Format RGB Vertical Stripe
Support Color 16.7M 72% NTSC
Service ODM, OEM, Customization
Resolution 1920(RGB)×1080, FHD
Size 21.5"


The DYMONA MxxxxX60-156-0601 TFT Display Module is the perfect solution for digital signage and outdoor high brightness applications. With 16.7M colors and 72% NTSC, this lcd display screen offers a full HD resolution of 1920(RGB)×1080. As the leading supplier of auo tft display, DYMONA is committed to providing excellent service, including ODM, OEM and customization. The operating temperature is -20 ~ 50 °C, and it is designed for reliable performance and durability.

The DYMONA MxxxxX60-156-0601 TFT Display Module is the perfect choice for any digital signage or outdoor high brightness application, with its outstanding full HD resolution and excellent color accuracy. Its robust design ensures reliable performance in any environment, and its comprehensive service offering of ODM, OEM and customization make it the ideal solution for any project.



DYMONA TFT Display Module (Model Number: MxxxxX60-156-0601) is a TFT/IPS display module which is designed for digital signage, outdoor high brightness applications. It supports 16.7M color and 72% NTSC, and its active area size is 476.064(W)×267.786(H) Mm. It can be used in a wide range of temperatures, from -20 to 60°C. The place of origin is Shenzhen. DYMONA TFT Display Module is ideal for your tft display touch, color lcd display module and outdoor tft display module needs.


Support and Services:

We offer technical support and services for our TFT Display Module products.

We provide free technical support via email, telephone, and online chat. Our technical support staff is available to answer any questions you may have.

We also offer a variety of services, such as repair and replacement services, to ensure that your TFT Display Module is functioning properly. We also offer training and installation services to help you get the most out of your TFT Display Module.


Packing and Shipping:

Packaging and Shipping of TFT Display Module:

The TFT Display Module is packaged in a corrugated cardboard box to provide superior protection during transit. The box is filled with foam material to provide cushioning to the module, and to ensure that the module is held securely in place. The box is then sealed with tape and labeled with the appropriate shipping information. The module is then ready to be shipped.



Q&A about DYMONA MxxxxX60-156-0601 TFT Display Module

Q1: What is the brand name and model number of the TFT Display Module?
A1: The brand name of the TFT Display Module is DYMONA, and the model number is MxxxxX60-156-0601.

Q2: Where is the TFT Display Module manufactured?
A2: The TFT Display Module is manufactured in Shenzhen.

Q3: What are the dimensions of the TFT Display Module?
A3: The dimensions of the TFT Display Module depend on the specific model and the type of TFT Display Module. Please contact us for more information.

Q4: What is the maximum resolution of the TFT Display Module?
A4: The maximum resolution of the TFT Display Module depends on the specific model and the type of TFT Display Module. Please contact us for more information.

Q5: What type of interface does the TFT Display Module support?
A5: The TFT Display Module supports various types of interface, including HDMI, USB, and DVI. Please contact us for more information.
