1920x1080 Resolution 13.3 LCD Screen 293.76x165.24mm LCD Screen Panel

  • 1920x1080 Resolution 13.3 LCD Screen 293.76x165.24mm LCD Screen Panel
  • 1920x1080 Resolution 13.3 LCD Screen 293.76x165.24mm LCD Screen Panel
  • 1920x1080 Resolution 13.3 LCD Screen 293.76x165.24mm LCD Screen Panel
  • 1920x1080 Resolution 13.3 LCD Screen 293.76x165.24mm LCD Screen Panel
Place of Origin Shenzhen
Brand Name DYMONA
Model Number M133X60-156-0601

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dimensions 12.2 X 8.3 X 0.3 In Active Area 293.76(W)×165.24(H) Mm
Good View At Symmetry Voltage Supply 3.3V (Typ.)
Pixel Format RGB Vertical Stripe Backlight 9S4P WLED , 15K Hours , With LED Driver
Size 13.3 Inch Viewing Angle 85/85/85/85 (Typ.)
High Light

13.3 LCD Screen 293.76x165.24mm

,

293.76x165.24mm LCD Screen Panel

,

1920x1080 Resolution 13.3 LCD Screen
Leave a Message
Product Description

Product Description:

Introducing the 13.3 inch LCD Screen Module, a high quality TFT LCD Screen Module with a size of 13.3 inches. It boasts an impressive 1920(RGB) x 1080 (FHD) resolution and a 9S4P WLED backlight, with an estimated lifespan of 15,000 hours and an LED driver. This LCD Screen Module has a voltage supply of 3.3V (Typ.) and operates at a temperature range of -20°C to 60°C. Its dimensions are 12.2 x 8.3 x 0.3 inches, making it the perfect size for any project. With its innovative design, high resolution, and reliable performance, this LCD Screen Module is sure to exceed your expectations.



Features:

  • Product Name: 13.3" LCD Screen Panel
  • Resolution: 1920(RGB)×1080
  • Interface: HDMI, VGA, DVI, eDP 30 Pins
  • Good View at: Symmetry
  • Active Area: 293.76(W)×165.24(H) Mm
  • Storage Temperature: -20-60°C
  • Voltage Supply: 3.3V (Typ.)


Technical Parameters:

Attribute Content
Brand BOE
Resolution 1920 x 1080
Color Gamut 72% NTSC
Response Time 30ms
Brightness 300 Cd/m2
Voltage Supply 3.3V (Typ.)
Viewing Angle 85/85/85/85 (Typ.)
Size 13.3 Inch
Dimensions 12.2 X 8.3 X 0.3 In
Type TFT LCD Screen Module
Storage Temperature -20-60°C


Applications:

Our products have a wide range of sizes, primarily 4.3inch to 43inch. They can be used in a variety of applications such as medical equipment, industrial control facilities, portable electrical impedance measurement, digital video camera display, vehicle equipment, aerospace equipment and Table PC.

In addition to those, they are used in Artificial Intelligence Robots, POS systems, automotive electronics, intelligent home applications, health care, advertising machines, exercise equipment and industrial control.



Customization:

13.3 Inch 1920*1080 FHD LCD Screen
  • Brand Name: DYMONA
  • Model Number: M133X60-156-0601
  • Place of Origin: Shenzhen
  • Voltage Supply: 3.3V (Typ.)
  • Pixel Format: RGB Vertical Stripe
  • Good View at: Symmetry
  • Type: LCD Screen
  • Active Area: 293.76(W)×165.24(H) Mm
  • Screen Size: 13.3 Inch
  • Resolution: 1920(RGB)×1080(FULL HD)


Support and Services:

Our 13.3 LCD Screen has a wide range of technical support and services available for our customers. Our technical support team is available 24/7 to help with any issues that may arise. We also offer a full warranty on our products, covering any manufacturing defects or part failures within the warranty period. We also have a dedicated after-sales service team who are on hand to help with any queries or concerns that may arise.



Packing and Shipping:

Packaging and Shipping 13.3 LCD Screen
Packaging
The 13.3 LCD Screen will be packaged in a cardboard box with customized foam inserts. It will also be wrapped in a plastic bag for additional protection before being placed in the box.
Shipping
The 13.3 LCD Screen will be shipped using a reliable courier service with tracking numbers and insurance to ensure safe delivery.


FAQ:

  • Q: What brand of 13.3 LCD Screen is it?
    A: It is DYMONA brand.
  • Q: What is the model number?
    A: The model number is M133X60-156-0601.
  • Q: Where is this 13.3 LCD Screen manufactured?
    A: It is manufactured in Shenzhen.
  • Q: What size is the 13.3 LCD Screen?
    A: It is 13.3 inches.
  • Q: What is the resolution of the 13.3 LCD Screen?
    A: The resolution is 1920x1080.
