3.3V 800:1 FHD TFT 13.3 LCD Screen For Industrial Automation

Place of Origin Shenzhen
Brand Name DYMONA
Model Number M133X60-156-0601

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Operating Temperature -20 ~ 60 °C Resolution 1920 X 1080
Backlight 9S4P WLED , 15K Hours , With LED Driver Type LCD Screen
Color Gamut 72% NTSC Response Time 30ms
Refresh Rate Refresh Rate Voltage Supply 3.3V (Typ.)
High Light

13.3 LCD Screen For Industrial Automation


800:1 FHD TFT 13.3 LCD Screen


3.3V 800:1 FHD TFT LCD Screen

Leave a Message
Product Description

3.3V 8001 FHD LCD Screen Display for Industrial Automation

Product Description:

The 13.3" LCD Screen Panel is an advanced display monitor that features a wide resolution of 1920x1080 and is equipped with a wide active area of 293.76(W)×165.24(H) mm. It also has a fast response time of 30ms, a brightness of 300 Cd/m2, and a backlight of 9S4P WLED with 15K hours of LED driver. Furthermore, it provides a storage temperature of -20-60°C, making it ideal for a variety of commercial and industrial applications. With its advanced features and extended temperature range, the 13.3" LCD Screen Panel is a reliable and cost-effective solution for any display monitor needs.



  • Product Name: 13.3 LCD Screen
  • Resolution: 1920x1080
  • Operating Temperature: -20 ~ 60 °C
  • Pixel Format: RGB Vertical Stripe
  • Response Time: 30ms
  • Dimensions: 12.2 X 8.3 X 0.3 In
  • Color Gamut: 72% NTSC
  • LCD Screen Panel: Tft Lcd Screen Module

Technical Parameters:

Parameter Value
Size 13.3" FHD (1920*1080)
Dimensions 12.2 X 8.3 X 0.3 In
Operating Temperature -20 ~ 60 °C
Backlight 9S4P WLED , 15K Hours , With LED Driver
Refresh Rate 60 Hz (Typ.)
Color Gamut 72% NTSC
Viewing Angle 85/85/85/85 (Typ.)
Pixel Format RGB Vertical Stripe
Interface HDMI, VGA, DVI,eDP 30 Pins
Type LCD Screen
Voltage Supply 3.3V (Typ.)


Our product portfolio covers a wide range of sizes, from 4.3 inch to 43 inch. Our full size LCD devices can be found in many industries such as medical instruments, industrial controls, portable electric impedance measuring devices, digital camera monitors, automobile electronics, AI robots, point-of-sale systems, intelligent homes, healthcare equipment, advertisement machines, exercise machines, and industrial controls.



13.3 LCD Screen

Brand Name:DYMONA

Model Number:M133X60-156-0601

Place of Origin:Shenzhen

Active Area:293.76(W)×165.24(H) Mm

Voltage Supply:3.3V (Typ.)

Backlight:9S4P WLED , 15K Hours , With LED Driver

Viewing Angle:85/85/85/85 (Typ.)

Dimensions:12.2 X 8.3 X 0.3 In

Highlight: FHD, 13.3", Resolution 1920x1080


Support and Services:

13.3 LCD Screen offers technical support and services to ensure customers have a positive experience with the product. Technical support services include installation and setup assistance, troubleshooting and repair guidance, and access to online and phone support services. Additionally, customers can access extended warranties and repair services, as well as access to parts and accessories. Customers can also access online product resources such as user manuals, FAQs, and product tutorials.


Packing and Shipping:

Packaging and Shipping for 13.3 LCD Screen

The 13.3 LCD Screen should be packaged securely in a box. The box should be cushioned and padded to protect against shock and vibration during shipping. The box should include all necessary information including the product description, serial numbers, weight, dimensions, and shipping address.

The box should be sealed with tape or other secure sealant. The box should be clearly labeled with the shipping address and other necessary information. The box should also include a Return Address in case the package needs to be returned.

The 13.3 LCD Screen should be shipped using a reliable shipping company such as FedEx or UPS. The package should be tracked and insured for its full value in case of any loss or damage during shipping.



Q1: What is the brand name of the 13.3 LCD Screen?

A1: The brand name of the 13.3 LCD Screen is DYMONA.

Q2: What is the model number of the 13.3 LCD Screen?

A2: The model number of the 13.3 LCD Screen is M133X60-156-0601.

Q3: Where is the 13.3 LCD Screen originally from?

A3: The 13.3 LCD Screen is originally from Shenzhen.

Q4: What size is the 13.3 LCD Screen?

A4: The 13.3 LCD Screen is 13.3 inches.

Q5: What is the resolution of the 13.3 LCD Screen?

A5: The resolution of the 13.3 LCD Screen is 1366 x 768.
