LCD 1000nit 11.6 Inch Laptop Display 60Hz Frequency 220Cd/M2 Brightness
| Place of Origin | Shenzhen |
|---|---|
| Brand Name | DYMONA |
| Model Number | MxxxxxX60-156-0601 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Surface Treatment | Antiglare, Hard Coating (3H) | Application | Netbook PC,Laptop |
|---|---|---|---|
| Operating Temperature | 0 ~ 50 °C | Type | LCD Module |
| Input Voltage | 3.3V | Brightness | 220 Cd/m² (Typ.) |
| Good View At | 6 O'clock | Viewing Angle | 3/7 |
| High Light | 1000nit 11.6 Inch Laptop Display,11.6 Inch Laptop Display 220Cd/M2 Brightness,11.6 Inch LCD Display 220Cd/M2 Brightness |
||
Product Description
1000nit LCD Display 60Hz Frequency 220 Cd/m² Brightness
Product Description:
The 11.6 LCD Screen is a perfect choice for any application requiring a high quality IPS LCD display. This 1000 nit LCD offers a high resolution TFT LCD module with a 256.125(W)×144(H) mm viewable area with a 60Hz frequency. With a MOQ of 1pcs, this panel is produced by the renowned Innolux brand. It is ideal for any application needing a reliable and consistent display.
Features:
- 11.6 Inch Laptop LCD Display
- Touch Screen: Without
- Viewing Angle: 3/7
- Surface Treatment: Antiglare, Hard Coating (3H)
- Interface: EDP 30pin
- Contrast Ratio: 500:1 (Typ.)
- tft lcd module
- laptop lcd screen
Technical Parameters:
| Parameters | Description |
|---|---|
| Product Name | 11.6 LCD Screen |
| Contrast Ratio | 500:1 (Typ.) |
| Good View at | 6 O'clock |
| Supplier Type | China Factory Directly Supply |
| MOQ | 1pcs |
| Brightness | 220 Cd/m² (Typ.) |
| Input Voltage | 3.3V |
| Response Time | 3/7 |
| Storage Temperature | -20 ~ 60 °C |
| Service | ODM /OEM /customization |
| Place of Origin | Shenzhen |
| Keywords | Laptop LCD Screen, IPS TFT LCD Display, IPS TFT LCD Display Manufacturers |
Applications:
The DYMONA MxxxxxX60-156-0601 11.6 inch laptop LCD panel is sourced from BOE and has a resolution of 1366(RGB)×768. With its EDP 30pin interface, it is designed to work with 3.3V input voltage and offers a view area of 256.125(W)×144(H) Mm. This laptop LCD screen panel is perfect for making laptops with an 11.6 inch display size.
Customization:
11.6 LCD Screen
Brand Name: DYMONA
Model Number: MxxxxxX60-156-0601
Place of Origin: Shenzhen
View Area: 256.125(W)×144(H) Mm
Resolution: 1366(RGB)×768
Viewing Angle: 3/7
Supplier Type: China Factory Directly Supply
Input Voltage: 3.3V
This 11.6 inch laptop LCD screen is perfect for your laptop! With brightness LCD and resolution up to 1366(RGB)×768, it will bring you the best viewing experience.
Support and Services:
Technical support and service for the 11.6 LCD Screen include:
- Troubleshooting assistance
- Free software upgrades
- Free technical support via phone, email or online chat
- Replacement parts and accessories
- Warranty repairs and replacements
Packing and Shipping:
Packaging and Shipping of the 11.6 LCD Screen:
The 11.6 LCD Screen will be packaged in a foam-padded box with bubble wrap protection to ensure it is transported safely. The box will be labeled with the product name, model number, and other relevant details. It will be shipped in a cardboard box with a tracking number. The box will be carefully secured using packing tape, and a delivery confirmation will be included in the package.
FAQ:
-
Q: What is the brand name of this LCD Screen?A: The brand name of this LCD Screen is DYMONA.
-
Q: What is the model number of this LCD Screen?A: The model number of this LCD Screen is MxxxxxX60-156-0601.
-
Q: Where is this LCD Screen from?A: This LCD Screen is from Shenzhen.
-
Q: What is the size of this LCD Screen?A: The size of this LCD Screen is 11.6 inches.
-
Q: What are the features of this LCD Screen?A: This LCD Screen has features of high brightness, high contrast and wide color gamut.
